Container Dollies
PINON - 16 Rue du Véxin - 78250 HARDRICOURT Tél : 01 30 99 92 00 Fax : 01 30 99 92 01
CONTAINER DOLLIES
Pinon was a part of the design and standardization of the
first container dollies made many decades ago.
Today our dollies meet all safety regulations and
international standards. Our dollies are design to be easy
to use and reliable for many years for minimal maintenance.
Container dolly with 2 front steering wheels
REF 1226-06
Specifications
- 2 Front steering wheels (option : 4 steering wheels)
- 360° turn table for transfer , lockable every 90°
- Flip-up automatic stops with vertical secured locks
- load capabilities : 1 LD3 61.5" x 60.4"
- option 1LD2 60.4" x 47"
- payload : up to 1.6tons
Container dolly with pivoting front axle, turn table and
“Fingers” for Loader interface - 2,5Tons
REF 1231-04
Specifications
- Front axle steering
- turntable with fingers for loader transfer
- load capabilities : 1LD8 ou LD4 96" x 60.4",
2LD2 47" x 60.4", 1LD3 61.5" x 60.4"
- payload : up to 2.5tons
Container dolly 1,6 T
REF 1204-06
Specifications
- Front axle steering
- turntable for side transfer
- Flip-up automatic stops with vertical secured locks
- load capabilities : 1 LD3 61.5" x 60.4"
- option 1LD2 60.4" x 47"
- payload : up to 1.6tons
Container dolly 2,5 T
REF 1231-05
Specifications
- Front axle steering
- turntable for side transfer
- load capabilities : 1LD8 ou LD4 96" x 60.4",
2LD2 47" x 60.4", 1LD3 61.5" x 60.4"
- payload : up to 2.5tons
DOUBLE LD2/LD3 Container dolly 3,5 T
REF 1240-10
Specifications
- Front + Rear steering wheels
- turntable for side transfer
- load capabilities : 2 LD2 or 2 LD3 or 1 LD1 or
1 LD6 or 1 LD8
- payload : up to 3.5tons
Dolly-To-Dolly Container tranfer 1.6Tons
REF 1250-01
Specifications
- Front + Rear steering wheels
- Turn table for container side transfer
- Flip-up automatic stops with vertical secured locks
- Load capabilities : 1LD3 61.5" x 60.4"
- option 1LD2 61.5" x 49"
- payload : up to 1.6Tons
Container dolly - steering front axle
Specifications
- Front steering axle
- Turn table for side transfer
- Flip-up automatic stops with vertical secured locks
- Load capabilities : 1LD3 61.5" x 60.4"
- option 1LD2 61.5" x 49"
- payload : up to 1.6Tons
